Microchip MRF24WB0MA/RM
Arup Das
8
1
0
IEEE 802.11-compliant RF Transceiver
Remove from Library
Add to Library
Open in Editor
Copy Symbol & Footprint
ECAD & Images
(2)
Datasheets
(1)
Datasheet
PDF
Used in Projects
(1)
Master2
hacknmod
Attributes
Part Number
MRF24WB0MA/RM
Conn 6 Type
input
Manufacturer
Microchip
Conn 5 Type
input
Description
IEEE 802.11-compliant RF Transceiver
Conn 4 Type
input
Prefix
U
Conn 3 Type
input
Conn 35 Type
power
Conn 2 Type
output
Conn 34 Type
input
Conn 0 Type
power
Conn 33 Type
input
Centroid Not Specified
No
Conn 32 Type
output
Mouser Part Number
579-MRF24WB0MARM
Conn 31 Type
output
Digikey Description
RF TXRX MODULE WIFI TRACE ANT
Conn 29 Type
power
Digikey Part Number
MRF24WB0MA/RM-ND
Conn 28 Type
power
Temperature Range High
+85°C
Conn 27 Type
power
Temperature Range Low
-40°C
Conn 26 Type
output
RoHS
yes
Conn 25 Type
input
Package
SMT_21MM0_31MM0
Conn 24 Type
power
Lead Free
yes
Conn 22 Type
input
Verified Pin Names
true
Conn 20 Type
input
Verified Attributes
true
Conn 19 Type
input
Verified Pad Assignment
true
Conn 18 Type
output
Verified Geometry
true
Conn 17 Type
output
Protocol
802.11b
Conn 16 Type
output
Frequency
2.4GHz
Conn 15 Type
input
Data Rate
2Mbps
Conn 9 Type
power
Voltage - Supply
2.7V ~ 3.6V
Conn 8 Type
input
