Texas Instruments TMS320F2808PZS
7
0
0
DSP Fixed-Point 32bit 100MHz 100MIPS 100-Pin LQFP
ECAD & Images (2)
Datasheets (1)
Datasheet
PDF
Attributes
Part Number
TMS320F2808PZS
Conn 30 Type
input
Manufacturer
Texas Instruments
Conn 29 Type
input
Description
DSP Fixed-Point 32bit 100MHz 100MIPS 100-Pin LQFP
Conn 28 Type
input
Prefix
U
Conn 27 Type
input
Conn 99 Type
I/O
Conn 26 Type
input
Conn 98 Type
I/O
Conn 25 Type
power
Conn 97 Type
I/O
Conn 24 Type
power
Conn 96 Type
I/O
Conn 23 Type
passive
Conn 95 Type
power
Conn 22 Type
input
Conn 94 Type
I/O
Conn 21 Type
input
Conn 93 Type
power
Conn 20 Type
input
Conn 92 Type
power
Conn 19 Type
input
Conn 91 Type
I/O
Conn 18 Type
input
Conn 90 Type
I/O
Conn 17 Type
input
Conn 89 Type
input
Conn 16 Type
input
Conn 88 Type
power
Conn 15 Type
input
Conn 87 Type
input
Conn 14 Type
power
Conn 86 Type
power
Conn 13 Type
power
Conn 85 Type
input
Conn 12 Type
power
Conn 84 Type
power
Conn 11 Type
power
Conn 83 Type
input
Conn 10 Type
power
Conn 82 Type
I/O
Conn 9 Type
power
Conn 81 Type
power
Conn 8 Type
I/O
Conn 80 Type
passive
Conn 7 Type
I/O
Conn 79 Type
passive
Conn 6 Type
I/O
Conn 78 Type
I/O
Conn 5 Type
I/O
Conn 77 Type
input
Conn 4 Type
I/O
Conn 76 Type
power
Conn 3 Type
I/O
Conn 75 Type
output
Conn 2 Type
power
Conn 74 Type
input
Conn 1 Type
power
Conn 73 Type
input
Conn 0 Type
I/O
Conn 72 Type
input
Ram Size
36KB
Conn 71 Type
I/O
Core Architecture
Harvard Bus
Conn 70 Type
I/O
Frequency
100MHz
Conn 69 Type
I/O
Interface
I2C,SPI,UART,CAN,SCI
Conn 68 Type
power
Max Supply Voltage
3.47V
Conn 67 Type
power
Memory Size
128KB
Conn 66 Type
I/O
Memory Type
FLASH
Conn 65 Type
passive
Min Supply Voltage
1.71V
Conn 64 Type
power
Number Of A/D Converters
1
Conn 63 Type
I/O
Number Of Adc Channels
16
Conn 62 Type
I/O
Number Of I/Os
35
Conn 61 Type
power
Number Of I2c Channels
1
Conn 60 Type
I/O
Number Of Pwm Channels
12
Conn 59 Type
I/O
Number Of Spi Channels
16
Conn 58 Type
power
Number Of Uart Channels
4
Conn 57 Type
I/O
Number Of Usb Channels
1
Conn 56 Type
I/O
Number Of Timers/Counters
16
Conn 55 Type
I/O
Mouser Description
Digital Signal Processors & Controllers - DSP, DSC 32-Bit Digital Sig Controller w/Flash
Conn 54 Type
power
Device Class L1
Integrated Circuits (ICs)
Conn 53 Type
I/O
Device Class L3
DSPs - Digital Signal Processors
Conn 52 Type
I/O
Device Class L2
Embedded Processors and Controllers
Conn 51 Type
I/O
Temperature Range Low
-40°C
Conn 50 Type
I/O
Temperature Range High
+125°C
Conn 49 Type
I/O
Standoff Height
0.05mm
Conn 48 Type
power
Mouser Part Number
595-TMS320F2808PZS
Conn 47 Type
I/O
Mfg Package Ident Rev
0
Conn 46 Type
I/O
Mfg Package Ident Date
0
Conn 45 Type
power
Mfg Package Ident
PZ0100A
Conn 44 Type
I/O
Max Junction Temp
+150°C
Conn 43 Type
I/O
Height
1.6mm
Conn 42 Type
I/O
Digikey Part Number
296-18335-ND
Conn 41 Type
power
Digikey Description
IC MCU 32BIT 128KB FLASH 100LQFP
Conn 40 Type
power
Centroid Not Specified
No
Conn 39 Type
power
RoHS
yes
Conn 38 Type
power
Package
LQFP100
Conn 37 Type
passive
Lead Free
yes
Conn 36 Type
output
Verified Pin Names
true
Conn 35 Type
output
Verified Attributes
true
Conn 34 Type
input
Verified Pad Assignment
true
Conn 33 Type
input
Verified Geometry
true
Conn 32 Type
input
Verification Version
0.0.0.1
Conn 31 Type
input
